Frame tubing

[Johan]

Hi all, I am new to this group. Can someboddy perhaps help me with a complete list of the tubing required for the LSA model, lenth, diameter, wall thikness?

Johan Botha

[Tailwheelflyer]

What plans number are you from bob?

[alaskabearhawk]

It's an easy, fun and necessary exercise to review the plans and make a list yourself. Bob never published a list in order to encourage the builder to take the time to read them.

[SpruceForest]

That is our story and we are sticking to it...

[Frank]

Recently there was a posting about VR3 Engineering in Ontario who apparently makes tubing kits for various aircraft.

https://vr3.ca/technical-documents/?mdocs-cat=mdocs-cat-1

FWIW, I noticed the LSA is listed with a diagram and inventory.

https://vr3.ca/?mdocs-file=6944


[SpruceForest]

If you have access to Adobe, right-click on the table contents on the VR3 LSA fuselage sheet and paste into an Excel worksheet. The usual sort by size or a pivot table should give you totals by size. As mentioned, use it to verify your own measurements.

I did this a while back for the land plane and seaplane versions of the Patrol and worked up the following:
